Table for user-defined parameter settings
Parameter list for DF51 frequency inverters.
For a detailed description of the parameters, see the specified
page in the manual (AWB8230-1540G).
Frequency inverters DF51-322-… (single- and three-phase mains
connection, rated voltage 230 V, 50/60 Hz) and DF51-340-…
(three-phase mains connection, rated voltage 400 V, 50/60 Hz)
work with the European operating system. The default settings are
listed in the DS column. The DF51-320-… devices can be used
only on three-phase AC mains (200/215/220/230/240 V,
50/60 Hz) and are supplied with the US version of the operating
system. The default values that apply here are shown in curly
brackets {xx}.
PNU = parameter number displayed on the LCD keypad.
RUN = access rights to parameters in RUN mode (RUN LED is lit):
b031 = 10 = extended access rights to parameters in RUN mode
(RUN LED is lit):
• j = enabled.
•– = disabled.
Enter your application-specific settings in the “User setting”
column in the table below.
h
The parameters of the second parameter set (PNU 2…)
always have the figure “2” in the first place and a grey
background in the table . On keypad DEX-KEY-…
they are displayed only when this function is enabled
(
a PNU C001 = 08: SET).
PNU RUN b031
= 10
Name Value range DS page User setting
A001
––
Reference value source
selection
00: Potentiometer (keypad) 01 87
01: Analog input: Control signal terminals
O and OI
02: Digital input (function PNU F001 or
A020) and keypad
03: Serial interface (Modbus)
10: Calculator (calculated value of CAL)
A201
––
Frequency reference value
source selection
(second parameter set)
Value a PNU A001 01 87
A002
A202
–
–
–
–
Start signal source selection
Start signal source selection
(second parameter set)
01: Digital input (FWD/REV) 01
01
70
70
02: START button (keypad)
03: Serial interface (Modbus)
Value a PNU A002
A003
––
Base frequency 30 – 400 Hz, up to value of PNU A004 [Hz] 50 {60} 66
A203
––
Base frequency
(second parameter set)
30 – 400 Hz, up to value of PNU A004 [Hz] 50 {60} 66
A004
––
End frequency (f
max
) 30 – 400 Hz 50 {60} 66
A204
––
End frequency (f
max
)
(second parameter set)
Values a PNU A004 50 {60} 66
A005
––
Analog input – selection (AT) On active AT signal (a PNU C001 = 16) a
changeover takes place between:
00 91
00: analog inputs O and/or OI
01: analog inputs O and OI (digital input is
ignored)
02: Analog input O or potentiometer
(keypad)
03: Analog input OI or potentiometer
(keypad)
A011
–
j Analog input (O-L) – frequency
at minimum reference value
0 – 400 Hz 0.0 89
