Moeller DF51 - Holding Register (Word Variable)

10/05 AWB8230-1541GB
Holding register (word
variable)
163
Holding register (word variable)
MSB = most significant bit
LSB = least significant bit
Holding
register
Function
code
Name Access
rights
Value range Manipulated
variable
hex
2 0000 Frequency reference input rw Active when PNU A001 = 03 (value range: 0 to
4000)
0.1 [Hz]
3 0000 Status of frequency inverter ro 00: Initialization –
01: (Reserved)
02: STOP mode
03: RUN mode
04: FRS, free coasting (free run stop)
05: JOG, jog mode
06: DB, DC braking
07: Ready for operation
08: AL, fault signal
09: Undervoltage
4 0000 Reserved ro – –
5 0000 Actual value signal PV input rw Active when PNU A076 = 02 (value range: 0 to
1000)
0.1 [%]
6 Reserved – – –
…
10
11 d080 Indication – total number of
occurred faults
ro – 1 [times]
12 d081 Indication – fault 1 (last
fault signal)
ro Fault signal E… –
13 d081 ro Reserved –
14 d081 ro Frequency (Hz) 0.1 [Hz]
15 d081
ro Reserved –
16 d081 ro Current (A) 0.1 [%]
17 d081
ro Internal DC link voltage (VDc) 1 [V]
18 d081 ro Total operating hours in RUN mode –
19 d081 ro Total operating hours in RUN mode 1 [h]
1A d081 ro Total Power On time, power supply connected (h) –
1B d081 ro Total Power On time, power supply connected (h) 1 [h]
