5 Setting parameters
You can adapt the DF51 to your specific applications. To do this,
you need to change the frequency inverter’s parameters with the
built-in keypad, the optional keypads DEX-KEY-… or the Drives-
Soft configuration software.
Table 20: Devices for changing parameter settings
This section lists the adjustable parameters.
For a clear overview, the parameters and settings are grouped
according to their respective functions.
PNU = parameter number displayed on the LCD keypad.
RUN = access rights to parameters in RUN mode (RUN LED is lit):
b031 = 10 = extended access rights to parameters in RUN mode
(RUN LED is lit):
• j = enabled.
•– = disabled.
Type Name Further optional accessories
Drives-Soft Parameterization software, executable on PCs with Windows
operating system. A CD is supplied with every DF51.
DEX-CBL-2M0-PC, prefabricated connecting cable with
interface converter
DEX-KEY-6 Keypad with digital display assembly and potentiometer. DEX-KEY-6
can be fitted externally.
DEX-CBL-…-ICS, prefabricated connecting cable with
RJ 45 plug.
DEX-MNT-K6, mounting rack, for example for flush
mounting in a control panel door.
DEX-KEY-61 Keypad with digital display assembly. DEX-KEY-61 can be fitted
externally.
DEX-KEY-10 External keypad with non-volatile parameter memory (copy function)
and a backlit two-section LCD display.
For notes about handling and parameterization, see manual
AWB8240-1416…
DEX-CBL-…-ICS, prefabricated connecting cable with
RJ 45 plug.
h
The parameter numbers of the second parameter set
(PNU x2xx) always start with a “2” and are shown with a
grey background in the table . On keypad DEX-KEY-
… they are displayed only when this function is enabled
(
a PNU C001 = 08: SET).
PNU Name RUN b031
= 10
Value Function DS
– – Parameters can not be changed in RUN mode (RUN LED is lit).
j – Parameters can be changed in RUN mode (RUN LED is lit).
– j Access rights for this parameter have been extended to include RUN
mode (a PNU b031= 10)
