Moeller DF51 - Page 168

Serial interface (Modbus)
10/05 AWB8230-1541GB
164
1C d082 Indication – fault 2 ro Fault signal E… –
1D d082 ro Reserved –
1E d082 ro Frequency (Hz) 0.1 [Hz]
1F d082 ro Reserved –
20 d082 ro Current (A) 0.1 [%]
21 d082 ro Internal DC link voltage (VDc) 1 [V]
22 d082
ro Total operating hours in RUN mode –
23 d082 ro Total operating hours in RUN mode 1 [h]
24 d082 ro Total Power On time, power supply connected (h) –
25 d082
ro Total Power On time, power supply connected (h) 1 [h]
26 d083 Indication – fault 3
ro Fault signal E… –
27 d083 ro Reserved –
28 d083 ro Frequency (Hz) 0.1 [Hz]
29 d083 ro Reserved –
2A d083 ro Current (A) 0.1 [%]
2B d083 ro Internal DC link voltage (VDc) 1 [V]
2C d083 ro Total operating hours in RUN mode 1 [h]
2D d083 ro Total operating hours in RUN mode –
2E d083
ro Total Power On time, power supply connected (h) 1 [h]
2F d083 ro Total Power On time, power supply connected (h) –
30 Reserved – – –
…
1000
1001 d001 Reserved ro – –
1002 d001 Output frequency display ro 0.0 – 400.0 Hz (0.1 Hz) 0.1 [Hz]
1003 d002 Output current display
ro 0.0 – 999.9 A (0.1 A) 0.1 [%]
1004 d003 Direction of rotation display
ro F: Clockwise (forward) rotating field
O: STOP
R: Anticlockwise (reverse) rotating field
–
1005 d004 PID feedback display
(MSB)
ro 0.00 – 99.99 (0.01 %)
100.0 – 999.9 (0.1 %)
1000 – 9999 (1 %)
0.0 – 400.0 Hz (0.1 Hz)
0.01
1006 d004 PID feedback display
(LSB)
ro
1007 d005 Indication – status of digital
inputs 1 to 5
ro – –
1008 d006 Indication – status of digital
outputs 11 and 12, and
relay K1
ro – –
1009 d007 Indication of scaled output
frequency (MSB)
ro 0.00 – 9999 (0.01/0.1/1/10 Hz) 0.01
100A d007 Indication of scaled output
frequency (LSB)
ro
100B d012 Reserved ro – –
Holding
register
Function
code
Name
Access
rights
Value range Manipulated
variable
hex
