Installation
10/05 AWB8230-1541GB
46
SK Operation with internal control voltage
SK • Operation with external control voltage +24 V)
• Reference point terminal L
a If reference point L is connected with the 0 V
potential of the external voltage source, the
external 24 V potential should be decoupled
through a diode.
SK • Operation with external control voltage from an
electronic device (for example PLC, easy)
• Reference point terminal L
a If reference point L is connected with the 0 V
potential of the external voltage source, the
external 24 V potential should be decoupled
through a diode.
Circuit example SR/SK switch Description
1
5
P24
L
0 V
SK
+24 V
–
+
R
i
R
i
1
5
P24
L
–
+
0 V
0 V
SK
+24 V+24 V
a
a
R
i
R
i
1
5
P24
L
–
+
0 V
0 V
SK
R
i
R
i
+24 V+24 V
a
a
