Motorola MC31XX Series - Rotating Scan Turret

Getting Started 1 - 3
Figure 1-2 MC31XXS and MC31XXR Mobile Computers (Back View)
Rotating Scan Turret
The MC31XXR mobile computer features a Rotating Scan Turret with three position stops. This feature offers
greater scanning flexibility.
Figure 1-3 Rotating Scan Turret
Handstrap
Scan Window
Stylus
MC31XXS
MC31XXR
Latches
Handstrap Screws
Stylus Holder
Headset Jack
(WLAN only)
Headset Jack
(WLAN only)
Scan Window
Speaker
Speaker
Handstrap
CAUTION Do not try to rotate turret past side position stops. Damage to device can occur.
Position Stop
Position Stop
Position Stop
