1 - 12 MC31XX Series Mobile Computer Integrator Guide
Performing a Cold Boot
A cold boot restarts the mobile computer and erases all user stored records and entries from RAM. Never perform
a cold boot unless a warm boot does not solve the problem.
To perform a cold boot:
1. Simultaneously press and then release the 1, 9 and Power keys. Do not hold down any other keys or buttons.
As the mobile computer initializes, the splash window, Figure 1-13, appears.
Figure 1-13
Splash Screen (Cold Boot)
2. Calibrate the touch screen. See Calibration Screen on page 1-10 to calibrate the mobile computer screen.
Windows Mobile 6.1 Devices
There are three reset functions, warm boot, cold boot and clean boot. A warm boot restarts the mobile computer
and closes all running programs. A cold boot also restarts the mobile computer and closes all running programs but
also initializes some drivers. Data saved in flash memory or a memory card is not lost.
Perform a warm boot first. This restarts the mobile computer and saves all stored records and entries. If the mobile
computer still does not respond, perform a cold boot.
Performing a Warm Boot
To perform a warm boot press the Power button for five seconds. As soon as the MC31XX starts release the
Power button.
Figure 1-14
Splash Screen (Warm Boot)
CAUTION Cold boot resets the mobile computer, to the default settings. All added applications and all stored data are
removed. Do not cold boot without support desk approval.
