Getting Started 1 - 15
Main Battery Removal
To remove the main battery from an MC31XXS/R:
1. If the MC31XXS/R is in suspend mode, press the Power button to wake the device.
2. Press the power button to place the MC31XXS/R in suspend mode.
3. Wait for the red Decode LED to turn on and then turn off.
4. Rotate the latches to the open position.
Figure 1-17
Open Latches
5. Lift the door off, bottom first.
Figure 1-18
Lift Battery Door
6. With finger, press the battery clip in (at the top of the battery) and lift the battery out top first.
NOTE On devices with Windows Mobile 6.5.3, a dialog box appears when pressing the Power button. See Removing
the Battery on page C-13 for more information.
CAUTION Do not lift up on the latches when removing the door. Lift up on the handstrap only.
WARNING! Do not use a tool to remove the battery.
