9 Operation
Maschinenfabrik Reinhausen GmbH 2022102 8595028/00 ENTAPCON
®
250
Description
I: K2 feedback If the input is active, the device activates
the input feedback K2.
I: TDSC® off If the input is active, the device activates
the input TDSC® off.
I: TDSC® on If the input is active, the device activates
the input TDSC® on.
I: VIM vacuum interrupter error (red) If the input is active, the device activates
the input VIM error vacuum interrupter.
I: VIM left If the input is active, the device activates
the input VIM left.
I: VIM center If the input is active, the device activates
the input VIM center.
I: VIM right If the input is active, the device activates
the input VIM right.
I: Local / Remote If the input is active, the device activates
the input LOCAL/REMOTE.
I: Auto / Manual If the input is active, the device activates
the input AUTO/MANUAL.
I: Stufenstellung Neutralposition If the input is active, the device activates
the input tap position neutral position
(Keep Track).
9.1.8.3 Digital outputs
The device features the option of assigning the following functions to the dig-
ital outputs
Description
O: Auto. If a signal is present at the input, the de-
vice activates the AUTO function.
O: Bandwidth < If a signal is present at the input, the de-
vice activates the function bandwidth
value above limit.
O: Bandwidth > If a signal is present at the input, the de-
vice activates the function bandwidth
value below limit.
O: Desired value 1 If a signal is present at the input, the de-
vice activates desired value 1.
O: Desired value 2 If a signal is present at the input, the de-
vice activates desired value 2.
O: Desired value 3 If a signal is present at the input, the de-
vice activates desired value 3.
O: Desired value 4 If a signal is present at the input, the de-
vice activates desired value 4.
