13 Technical data
Maschinenfabrik Reinhausen GmbH 2022 1898595028/00 EN TAPCON
®
250
Interface Pin Description
1
2
3
4
5
6
7
8
9
10
10 Common reference (common)
9 Common reference (common)
8 Input 17
7 Input 16
6 Input 15
5 Input 14
4 Input 13
3 Input 12
2 Input 11
1 Input 10
Table72: ConnectorX2 (group 1)
13.2.7 Digital inputs DI 16-110V
DI 16-110V
Inputs 2 x 8, plug-based electrical isolation
Nominal voltage 110VDC
120 VAC (bei 50 Hz +-10%; 60 Hz +-10%)
Max. operating voltage 143VDC
144VAC
Logical0 ≤ 55V
Logical 1 ≥ 82.5V
Input current 0.9mA
Simultaneity factor (at 65°C
ambient temperature)
Max. 13 inputs
Table73: DI16-110V assembly technical data
