4.4.3.1.3 G1 power supply
The G1 assembly provides the energy supply of the product.
Figure11: G1 assembly
4.4.3.1.4 Power supply PS
The PS assembly contains the power supply unit for supplying power to the
ISM® assemblies. The RY LED signals that the assembly is ready for opera-
tion.
1
2
3
4
X1
SICAM A8000
PS - 8640
+
-
RY
Figure12: PS assembly
