4 Product description
Maschinenfabrik Reinhausen GmbH 202232 8595028/00 ENTAPCON
®
250
4.4.3.1.5 Digital inputs DI 16-24V
The DI 16-24V assembly has 16 digital inputs with a nominal voltage of
24VDC. The RY LED signals that the assembly is ready for operation.
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
X2
X1
RY
SICAM A8000
DI - 811x
Figure13: DI16-24V assembly
4.4.3.1.6 Digital inputs DI 16-110V
The DI 16-110V assembly has 16digital inputs with a nominal voltage of
110VDC/AC. The RY LED signals that the assembly is ready for operation.
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
X2
X1
RY
SICAM A8000
DI - 811x
Figure14: DI16-110V assembly
