Model 493.02 Controller Service
Index
244
calibration
AC conditioners (displacement) 99
DC conditioners (force) 128
encoders 161
gain controls 135
hydraulics turn on 108, 132, 165, 171
LVDT 99
phase adjustment 110
shunt 89
shunt, performing 89
Temposonics sensors 167
using full-range conditioner 98
calibration file
resource assignment 164
CE EMC compliance
cabling 40
chassis
grounding 32
installation options 30
power connections 32
power description 33
CLC control 198
command sources 197
conditioner
polarity 73
configurations
AC power 34
connecting
electrical power 32
connection
workstation 56
connections
AC power 34
chassis ground 32
encoders 161
multiple controllers 43
System I/O module 58
control modes
characteristics 196
CLC 198
displacement 197
dual compensation 198
force 197
strain 197
controller
automated configuration 23
back panel 21
basic functions 22
front panel 20
handle kit install 36
interlocks 22
mounting requirements 24
multiple connections 43
plug-in modules 21
stand alone configuration 20
controller scope
tuning use 213
D
d gain. see derivative gain
daughter boards 28
DC conditioners
calibration 128
checking polarity 133
DC sensor calibration
shunt calibration 89
shunt resistor table 90
delta P sensors, stabilizing with 204
derivative gain 202
digital inputs
cable specification 68
J54 Dig In connector 68
digital outputs
cable specification 69
J55 Dig Out connector 69
displacement
calibrate actuator retraction 114
mounting dial indicator 111
sensor calibration 99
displacement control 197
displacement tuning 215
auto tune 218
prerequisites 215
procedure 215
when to tune 215
dither
about 76
adjusting dither amplitude 76
dual compensation control 198
E
emergency stop
cable specifications 63
E-stop out connector (J29) 62
HPU transition connectors 62
encoder calibration
calibration file 164
connections 161
defining an input 161
setting resolution 164
setting zero 161, 165
signal monitoring 163
error signal 212
