DISTINTA ARTICOLI
M.Gi.
24/05/2021
03/06/2021
REV.
REV.
R.B.
Contr.
Ap.
R.B.
Dis.
Dis.
0
Vers. MX 250
0
Distinta articoli MTEL_F01_003
Q.tà
SEF Numero articoloNumero PPS
Codice
Descrizione
Lunghezza
Omesso
in DB
Luogo di montaggio
Descrizione
1
FC26 ZCMD21L101E0473 [1SCMX6.15.12-A.429] CORPO+CAVO 1NC+1NO (RAPIDO) L 10 m
7 m
SC_STAB
1
FC26 ZCE011E0004 [1SCMX6.15.12-A.429] TESTA ROTANTESC_STAB
1
FC26 ZCY161E0009 [1SCMX6.15.12-A.429] LEVA ROTANTESC_STAB
1
FC26 PCLT-07B008420-07B [1SCMX6.15.12-A.429] TUBO FLEX. COPRICAVI I-PCLT 07B
6 mX
SC_STAB
1
FC37 XS618B1PAM121E0290 [1SCMX6.15.12-A.429] PROXIMITY M18 1NO con CONNETTORE M12SC_STAB
1
FC38 XS618B1PBM121E0690 [1SCMX6.15.12-A.429] PROXIMITY M18 1NC con CONNETTORE M12SC_STAB
1
FC50 XS7F1A1PBL01M81E0692-1 [1SCMX6.15.12-A.429] PROXIMITY 1NC CAVO 0,15m CON CONNETTORE M8 3pin MASCHIOSC_STAB
1
FC51 XS7F1A1PBL01M81E0692-1 [1SCMX6.15.12-A.429] PROXIMITY 1NC CAVO 0,15m CON CONNETTORE M8 3pin MASCHIOSC_STAB
1
FC51A M30 1NC XS130B3PBM121E0693 [1SCMX6.15.12-A.429] PROXIMITY M30 1NC XS130B3PBM12SC_STAB
1
FC52 XS7F1A1PBL01M81E0692-1 [1SCMX6.15.12-A.429] PROXIMITY 1NC CAVO 0,15m CON CONNETTORE M8 3pin MASCHIOSC_STAB
1
FC52A M30 1NC XS130B3PBM121E0693 [1SCMX6.15.12-A.429] PROXIMITY M30 1NC XS130B3PBM12SC_STAB
1
FC53 XS7F1A1PBL01M81E0692-1 [1SCMX6.15.12-A.429] PROXIMITY 1NC CAVO 0,15m CON CONNETTORE M8 3pin MASCHIOSC_STAB
1
FC73 XS618B1PAM121E0290 [1SCMX6.15.12-A.429] PROXIMITY M18 1NO con CONNETTORE M12SC_STAB
1
FC74 XS618B1PAM121E0290 [1SCMX6.15.12-A.429] PROXIMITY M18 1NO con CONNETTORE M12SC_STAB
1
FC82 ZCMD291E0065 [1SCMX6.15.12-A.429] CORPO 2NC SCATTO RAPIDOSC_STAB
1
FC82 ZCMC29L71E0066 [1SCMX6.15.12-A.429] CAVO 2NC L 7 m_ PER FINECORSA ZCMD29
6,5 m
SC_STAB
1
FC82 ZCE011E0004 [1SCMX6.15.12-A.429] TESTA ROTANTESC_STAB
1
FC82 ZCY161E0009 [1SCMX6.15.12-A.429] LEVA ROTANTESC_STAB
1
FC83 ZCMD291E0065 [1SCMX6.15.12-A.429] CORPO 2NC SCATTO RAPIDOSC_STAB
1
FC83 ZCMC29L71E0066 [1SCMX6.15.12-A.429] CAVO 2NC L 7 m_ PER FINECORSA ZCMD29
5,5 m
SC_STAB
1
FC83 ZCE011E0004 [1SCMX6.15.12-A.429] TESTA ROTANTESC_STAB
1
FC83 ZCY161E0009 [1SCMX6.15.12-A.429] LEVA ROTANTESC_STAB
1
FC102 ZCMD291E0065 [1SCMX6.15.12-A.429] CORPO 2NC SCATTO RAPIDOSC_STAB
1
FC102 ZCMC29L71E0066 [1SCMX6.15.12-A.429] CAVO 2NC L 7 m_ PER FINECORSA ZCMD29
6,5 m
SC_STAB
1
FC102 ZCE011E0004 [1SCMX6.15.12-A.429] TESTA ROTANTESC_STAB
1
FC102 ZCY161E0009 [1SCMX6.15.12-A.429] LEVA ROTANTESC_STAB
1
FC103 ZCMD291E0065 [1SCMX6.15.12-A.429] CORPO 2NC SCATTO RAPIDOSC_STAB
1
FC103 ZCMC29L71E0066 [1SCMX6.15.12-A.429] CAVO 2NC L 7 m_ PER FINECORSA ZCMD29
5,5 m
SC_STAB
1
FC103 ZCE011E0004 [1SCMX6.15.12-A.429] TESTA ROTANTESC_STAB
1
FC103 ZCY161E0009 [1SCMX6.15.12-A.429] LEVA ROTANTESC_STAB
1
FS01 DIN 72581-15A002921-15 [1SCMX6.15.12-A.429] Fusibile a lama 15A
X
SC_STAB
1
FS03 DIN 72581-4A002921-4 [1SCMX6.15.12-A.429] Fusibile a lama 4A
X
SC_STAB
1
FS04 DIN 72581-4A002921-4 [1SCMX6.15.12-A.429] Fusibile a lama 4A
X
SC_STAB
1
FS10 DIN 72581-7,5A002921-7,5 [1SCMX6.15.12-A.429] Fusibile a lama 7,5A
X
SC_STAB
1
FS18 DIN 72581-4A002921-4 [1SCMX6.15.12-A.429] Fusibile a lama 4A
X
SC_STAB
1
FS40 DIN 72581-2A002921-2 [1SCMX6.15.12-A.429] Fusibile a lama 2A
X
SC_STAB
1
FSMTEL DIN 72581-20A002921-20 [1SCMX6.15.12-A.429] Fusibile a lama 20A
X
SC_STAB
1
FSMTEL MT0100359008376 [1SCMX6.15.12-A.429] COPERCHIO FUSIBILE MTA
X
SC_STAB
