Use and warning instructions in compliance with EC regulations - Page 56
7.6. STOP PROCEDURES
7.6.1. END-OF-WORK STOP
To stop the machine, proceed as follows:
STEP ACTION
1
After having put the platform in idle mode, fully retract the outriggers. The complete retraction of the outriggers
is confirmed by the turning off of the special red located in the vehicle cab.
2
Once all the outriggers are retracted and before moving the vehicle, disconnect the power take-off. A red light
in the vehicle cab turns off when the power take-off is disengaged.
ATTENTION!
Travelling with the power take-off engaged can cause serious damage to the
hydraulic pump or speed shift. Do not move the vehicle if the light is on.
3 Move or park the carriage as if it were a regular vehicle.
