ATTENTION!
Operators and managers are required to:
♦ make sure that the required plates are all present, fully visible and legible;
♦ immediately replace any plate that is illegible or that has been removed (to request any
replacement plates, contact MULTITEL PAGLIERO S.p.A.)
3.14.1. SAFETY PICTOGRAMS AFFIXED TO THE MACHINE
The image below shows the location, on the machine, of the plates bearing the warning, prohibition and prescription signs
that the operat has to keep in mind.
Below are the signs installed on the machine:
16
2
5
7
4
78
6
4
POS. SIGN DESCRIPTION
1
Sound level sign. Protect hearing by wearing the special earmuffs.
2
Sign concerning the maximum carrying capacity of the basket and the maximum number of
operators that the basket can hold.
3
Indication of the machine greasing points.
(Yellow colour)
See the spare parts catalogue "Annex"
