SECTION 6
Controls
6. CONTROLS
The platform for aerial work is equipped with the following control devices:
POS. COMPONENT DESCRIPTION
1
DEVICE FOR OUTRIGGER MOVEMENT
They contain the controls used to move the outriggers. As an
option, they can be the automatic type.
2
DEVICE FOR BOOM MOVEMENT FROM THE
BASKET
It includes all the boom controls and functions.
3
DEVICE FOR BOOM MOVEMENT FROM THE
BASE
It includes all the boom controls and functions.
The controls from the base include a two-position selector (see paragraph “CONTROLS FROM THE BASE”), which is used
to activate the controls from the basket or those from the base. The activation of one set of controls automatically deacti-
vates the others. When selecting the controls from the basket, you need to subsequently remove the key from the selector
in order to prevent improper use.
The extra key, which is supplied with the equipment, must be kept in the vehicle cabin for emergencies.
6.1. OUTRIGGER CONTROLS
Each lever corresponds to one number, the numbers identify the outrigger that is being moved.
POS. OUTRIGGER CONTROL DESCRIPTION
1
FRONT LEFT Push the lever to raise the outrigger, pull the lever to lower it.
2
REAR LEFT Push the lever to raise the outrigger, pull the lever to lower it.
3
REAR RIGHT Push the lever to raise the outrigger, pull the lever to lower it.
4
FRONT RIGHT Push the lever to raise the outrigger, pull the lever to lower it.
