Use and warning instructions in compliance with EC regulations - Page 42
POS. DESCRIPTION
16
Red indicator. Danger signal.
The cage is fitted with a hydraulic circuit that automatically maintains its horizontal position.
When the indicator is on, it means that the horizontal position of the cage has exceeded an inclination of 10°. The
movements of the second boom, which would tend to make the situation even worse, are inhibited.
To restore proper cage positioning, use the special cage controls lever (see position 10).
17
Optional. Red indicator. Danger signal.
When the indicator is on, it means thatthe door has not been closed correctly. No movement is allowed when this
indicator is on. The door must be properly closed to resume movements.
18
Optional. Red indicator. Danger signal.
When this indicator is on, it means that the maximum weight that can be loaded in the cage has been reached. No
movement is allowed when this indicator is on.
19
Optional. Red indicator. Danger signal.
When the indicator is on, it means the cage is not properly installed on its support (for platforms equipped with
removable cage)
20
Optional. Duplication of the configuration selector of the left side outriggers.
21
Optional. Duplication of the configuration selector of the right side outriggers.
6.3. CONTROLS FROM BASE-CAGE
The operator can access the controls directly from the cage (see “CAGE CONTROLS ”), or lower the cage to the ground,
using the controls located at the cart level.
To move the aerial platform, you need to select the type of movement you wish to achieve by using the designated levers,
at the same time using the joystick in a proportional manner in order increase and adjust the speed of the pre-selected
movement.
ATTENTION!
You will need to start and stop the manoeuvres gradually, avoiding starting and stopping suddenly.
Sudden starts and stops can cause vibrations on the valves. In this case, stop moving it and start
over again, more gradually.
