Use and warning instructions in compliance with EC regulations - Annex
OPTIONS
230V ELECTRICAL OUTLET
This platform is equipped with a 230V external mains connection outlet to have power supply in the cage.
ATTENTION!
The external power supply cable and source (not supplied) must be up to standard and have ad-
equate features to the type of power required. In particular, the cable must have sufficient section
for the length, power, etc..
It is recommended to use a connection cable with a 4 mm² wire section and a maximum length of
20-25 m for proper operation.
For the timely detection of malfunctions before a hazardous situation for the user is generated, the cage supply
management box must be checked every month.
This check must be carried out as follows:
•Powerwithanyoftheoptionsprovided(plugsorturningthegeneratoron,ifpresent)andactivatethegeneral
protection device and check the state of the differential protection by means of the relevant test button T.
•Visualcheckoftheintegrityofthecomponents
•Checkthestateofanysupplymanagementcontactorsbyconnectingthesuppliesindividuallyandverifyingthe
activation and deactivation of the relevant contactors.
ATTENTION!
Disconnect all sources before carrying out any work that requires opening the box.
ATTENTION!
When working on parts of the wiring, be sure to disconnect the vehicle panel
