Use and warning instructions in compliance with EC regulations - Annex
IDENTIFICATION
VALVES FOR EMERGENCY DESCENT
CODE POSITION
Y12
Y38
Behind the turret, next to the movements distributor.
Y2
Y21
Y121
Y122
Positioned on the cart frame next to the outriggers distributor.
These seals can be restored by the operator, if properly trained, after restoring the initial conditions (position of hand wheel
valves, etc..) and having contacted the assistance service to evaluate the case.
CONTROL AND CALIBRATION DEVICES
CODE POSITION
PR1
PR2
PR3
PR4
On the jib orientation jack. The valves are covered by a casing, the fi xing screws of which are sealed.
Y36
Y37
Behind the turret, next to the movements distributor.
These seals can only be restored by a qualifi ed technician as they protect the safety settings.
