NETGEAR Nighthawk D7000 User Manual

DescriptionField
View or Change the Basic WiFi Settings on page 102). For information about configuring WEP,
see Configure WEP Legacy WiFi Security on page 112.
•
WPA-PSK [TKIP].WPA provides a secure connection but is superseded by WPA2.The WPA-PSK
[TKIP] option displays only if you configure the WiFi mode for the main WiFi network as Up to
54 Mbps in the 2.4 GHz band (see View or Change the Basic WiFi Settings on page 102).
To use WPA security, in the Passphrase field, enter a phrase of 8 to 63 characters.To join the
2 .4 GHz band of the guest WiFi network, a user must enter this passphrase.
•
WPA2-PSK [AES]. WPA2 provides a secure and fast connection but some older WiFi devices
do not detect WPA2 and support only WPA. Select WPA2 to allow 802.11n devices to connect
to the 2.4 GHz band of the guest WiFi network at the fastest speed. If your network includes older
devices that do not support WPA2, select WPA-PSK [TKIP] + WPA2-PSK [AES] security.
To use WPA2 security, in the Passphrase field, enter a phrase of 8 to 63 characters.To join the
2.4 GHz band of the guest WiFi network, a user must enter this passphrase.
•
WPA-PSK [TKIP] + WPA2-PSK [AES].This type of security enables WiFi devices that support
either WPA or WPA2 to join the 2.4 GHz band of the guest WiFi network. However, WPA-PSK
[TKIP] is less secure than WPA2-PSK [AES] and limits the speed of WiFi devices to 54 Mbps.
To use WPA + WPA2 security, in the Passphrase field, enter a phrase of 8 to 63 characters.To
join the 2.4 GHz band of the guest WiFi network, a user must enter this passphrase.
•
WPA/WPA2 Enterprise.This type of security requires that your WiFi network can access a
RADIUS server. For information about configuring WPA/WPA2 Enterprise, see Configure
WPA/WPA2 Enterprise WiFi Security on page 109.
The passphrase that provides users access to the guest
WiFi network in the 2.4 GHZ band. The passphrase is also
referred to as the password or key.
Passphrase
Wireless Network (5GHz a/n/ac)
The SSID is the 5 GHz WiFi band name. If you did not
change the SSID, the default SSID displays, which is
Name (SSID)
NETGEAR-5G_Guest1.To change the SSID in the 5 GHz
WiFi band for the guest WiFi network, enter a 32-character
(maximum), case-sensitive name in this field.
This field is of an informational nature and shows the channel
that is configured in the 5 GHz band for the main WiFi
Channel
network.You cannot change the channel in the 5 GHz band
for the guest WiFi network.
This field is of an informational nature and shows the mode
that is configured in the 5 GHz band for the main WiFi
Mode
Manage the WiFi Network Settings
121
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
