NETGEAR Nighthawk D7000 User Manual

The information onscreen uses the following color coding:
• A green flag indicates that the cable connection or Internet connection is fine and no problems
exist. For a WiFi network, the network is enabled and secured.
• A red X indicates that configuration problems exist for the cable connection or Internet connection
or the connection is down. For a WiFi network, the network is disabled or down.
• An amber exclamation mark indicates that the cable port or Internet port is configured but cannot
get an Internet connection (for example, because the cable is disconnected), that a WiFi network
is enabled but unprotected, or that another situation that requires your attention occurred.
The following table describes the fields of the six panes on the ADVANCED Home page.
DescriptionField
Router Information
The modem router model.Hardware Version
The version of the modem router firmware. If you upgrade the
firmware on the modem router, the version changes.
Firmware Version
The version of the modem router firmware. If you upgrade the
firmware on modem router, the version changes.
GUI Language Version
LAN Port
The settings of the LAN port. For information about how to configure the LAN settings, see Manage
the Modem Router’s LAN IP Address Settings on page 219 and Disable the Built-In DHCP Server on
page 227.
The Media Access Control (MAC) address.This address is the
unique physical address that is assigned to the Ethernet LAN
port.
MAC Address
The IP address that the Ethernet LAN port uses.The default
IP address is 192.168.0.1.
IP Address
Displays whether the DHCP server of the modem router is
enabled for devices that are attached to the LAN.
DHCP
Internet Port
The settings of Internet port.The Internet connection can run through the ADSL port with DSL service
or through the WAN Ethernet port with cable or fiber service. For information about how to configure
the Internet settings, see one of the following sections:
Manage the Modem Router and Monitor the Traffic
243
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
