DescriptionField
•
Set Up Your Modem Router for DSL Service on page 24
•
Set Up the Modem Router for Cable or Fiber Service on page 32
•
Manually Set Up an ADSL Internet Connection on page 51
•
Manually Set Up a VDSL Internet Connection on page 63
•
Manually Set Up a Cable or Fiber Internet Connection on page 73
The Media Access Control (MAC) address.This address is the
unique physical address that is assigned to the Internet port.
MAC Address
The IP address that the Internet port uses. If this field does not
display an address or displays 0.0.0.0 as the address, the
modem router is not connected to the Internet.
IP Address
The type of Internet connection, which can be a PPPoE
connection, PPPoA connection, fixed IP address connection,
or DHCP connection.
Connection
The IP subnet mask that the Internet port uses.IP Subnet Mask
The IP address of the gateway that the Internet port uses.Gateway IP Address
The IP address of the Domain Name System (DNS) server that
the Internet uses.
Domain Name Server
Wireless Settings (2.4GHz)
The settings of the WiFi port for the 2.4 GHz band of the main network. For information about how
to configure the settings of the main network, see the following sections:
• Manage the Basic WiFi Settings and WiFi Security of the Main Network on page 102
• Control the WiFi Radios on page 123
• Manage Advanced WiFi Features on page 129
The WiFi network name for the 2.4 GHz band of the main
network.
Name (SSID)
The location (country).Region
The channel that the 2.4 GHz band of the main network uses.Channel
Manage the Modem Router and Monitor the Traffic
244
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
