Figure 7. Modem router cabling for cable or fiber service
To connect your modem router to a cable or fiber service:
1. Unplug your cable or fiber modem’s power, leaving the modem connected to the wall jack for your
Internet service.
2. If your cable or fiber modem includes a battery backup, remove the battery.
3. Use an Ethernet cable to connect the cable or fiber modem to the red Internet port on the modem
router.
4. If your cable or fiber modem includes a battery backup, reinsert the battery.
5. Plug in and turn on your cable or fiber modem.
6. Connect the power adapter to the modem router and plug it into an electrical outlet.
Wait for the Power LED to light solid white, which takes about two minutes.
7. If the Power LED does not light, press the Power On/Off button.
8.
Wait for the WiFi LED to light solid white.
If the WiFi LED does not light, press the WiFi On/Off button .
9. Connect a computer to the modem router by one of the following methods:
•
Ethernet cable. Use an Ethernet cable to connect your computer to a yellow Ethernet LAN port
on the modem router.
The product package contains a yellow Ethernet cable.
Your computer connects to the modem router’s LAN.
•
WiFi. Connect to the default WiFi network of the modem router:
a. On your computer or WiFi device, find and select the WiFi network.
The WiFi network name (SSID) is on the product label.
b. Join the WiFi network and enter the WiFi password.
Install and Access the Modem Router and Its Network
33
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
