Enable QoS and automatically set the
Internet bandwidth
You can enable QoS and let the AP automatically set its Internet download and upload
bandwidth based on an automated speedtest. Although can you manually set the
download and upload speed (see Enable QoS and manually set the Internet bandwidth
on page 106), we recommend that use the automatic method that is described in the
following procedure.
To enable QoS and set the Internet download and upload bandwidth based on a
speedtest:
1.
Connect your computer or mobile device to the AP in one of the following ways
•
Connect directly to the AP’s WiFi network or LAN. (Applies to the AP in either
operation mode.)
•
Connect to the same network that the AP is connected to. (Applies only if the AP
is operating in AP mode.)
2.
Launch a web browser and enter http://www.routerlogin.net in the address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use routerlogin.net on page 32.
A login window displays.
If your browser displays a security warning, dismiss the warning. For more information,
see Dismiss a browser security warning on page 38.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The BASIC Home page displays.
4.
Select BASIC > Quality of Service.
The QoS Setup page displays. By default, Quality of Service (QoS) is enabled, and
the Enable QoS check box is selected.
5. Click the Take A Speedtest button.
The speed test checks the AP download and uplink bandwidth, sets the detected
bandwidths, and displays the results on the page.
6. Click the Apply button.
Your settings are saved.
User Manual105Optimize Performance
WiFi 6 AX1800 Dual Band Wireless Access Point WAX204
