NETGEAR WiFi 6 AX1800 User Manual

Set up an IPv6 DHCP Internet connection [router mode]
To set up an IPv6 Internet connection with a DHCP server:
1.
Launch a web browser from a computer or mobile device that is connected to a WiFi
network or LAN port on the AP.
2.
Enter http://www.routerlogin.net in the address field.
A login window displays.
If your browser displays a security warning, dismiss the warning. For more information,
see Find the IP address of the AP when you cannot use routerlogin.net on page 32.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > IPv6.
The IPv6 page displays.
5. From the Internet Connection Type menu, select DHCP.
The page adjusts. The AP automatically detects the information in the following
fields:
•
Router’s IPv6 Address on WAN. This field shows the IPv6 address that is acquired
for the AP’s WAN (or Internet) interface. The number after the slash (/) is the length
of the prefix, which is also indicated by the underline (_) under the IPv6 address.
If no address is acquired, the field displays Not Available.
•
Router’s IPv6 Address on LAN. This field shows the IPv6 address that is acquired
for the AP’s LAN interface. The number after the slash (/) is the length of the prefix,
which is also indicated by the underline (_) under the IPv6 address. If no address
is acquired, the field displays Not Available.
6.
(Optional) In the User Class (if Required) field, enter a host name.
Most people can leave this field blank, but if your ISP gave you a specific host name,
enter it here.
7.
(Optional) In the Domain Name (if Required) field, enter a domain name.
You can type the domain name of your IPv6 ISP. Do not enter the domain name for
the IPv4 ISP here. For example, if your ISP’s mail server is mail.xxx.yyy.zzz, type
xxx.yyy.zzz as the domain name. If your ISP provided a domain name, type it in this
field. For example, Earthlink Cable might require a host name of home, and Comcast
sometimes supplies a domain name.
User Manual59Manually Set Up Internet
Settings [Router Mode]
WiFi 6 AX1800 Dual Band Wireless Access Point WAX204

NETGEAR WiFi 6 AX1800 Specifications

General

WiFi Technology	WiFi 6 (802.11ax)
Maximum WiFi Speed	1.8Gbps
Bands	Dual-band
Ethernet Ports	1 x Gigabit Ethernet
MU-MIMO	Yes
Beamforming	Yes
Security	WPA3
OFDMA	Yes
Wireless Speed	600 Mbps (2.4 GHz) + 1200 Mbps (5 GHz)
Antenna	Internal antennas
Power Source	Power adapter
