Router’s IPv6 Address on LAN. This field shows the IPv6 address that is acquired
for the AP’s LAN interface. The number after the slash (/) is the length of the prefix,
which is also indicated by the underline (_) under the IPv6 address. If no address
is acquired, the field displays Not Available.
6. In the LAN Setup section, select an IP Address Assignment radio button:
•
Use DHCP Server. This method passes more information to LAN devices but
some IPv6 systems might not support the DHCPv6 client function.
•
Auto Config. This is the default setting.
This setting specifies how the AP assigns IPv6 addresses to the devices on your home
network (the LAN).
7.
(Optional) In the LAN Setup section, select the Use This Interface ID check box and
specify the interface ID to be used for the IPv6 address of the AP’s LAN interface.
If you do not specify an ID here, the AP generates one automatically from its MAC
address.
8. Select an IPv6 Filtering radio button:
•
Secured. In secured mode, which is the default mode, the router inspects both
TCP and UDP packets.
• Open. In open mode, the router inspects UDP packets only.
9. Click the Apply button.
Your settings are saved.
Use Auto Config for an IPv6 Internet connection [router
mode]
To set up an IPv6 Internet connection through autoconfiguration:
1.
Launch a web browser from a computer or mobile device that is connected to a WiFi
network or LAN port on the AP.
2.
Enter http://www.routerlogin.net in the address field.
A login window displays.
If your browser displays a security warning, dismiss the warning. For more information,
see Find the IP address of the AP when you cannot use routerlogin.net on page 32.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
User Manual51Manually Set Up Internet
Settings [Router Mode]
WiFi 6 AX1800 Dual Band Wireless Access Point WAX204
