In access point mode, the IP address is a LAN IP address. In router mode, the IP
address is a WAN IP address.
•
DHCP Server. The IP address for the Dynamic Host Configuration Protocol server
that provides the TCP/IP configuration to the AP.
In access point mode, the IP address is a LAN IP address. In router mode, the IP
address is a WAN IP address.
•
DNS Server. The IP address of the Domain Name Service server that provides
translation of network names to IP addresses.
In access point mode, the IP address is a LAN IP address. In router mode, the IP
address is a WAN IP address.
•
Lease Obtained. The date and time when the DHCP IP address lease was
obtained.
•
Lease Expires. The date and time that the DHCP IP address lease expires.
6.
When the AP receives an IP address dynamically, you can perform the following
actions:
•
Release. Click the Release button to terminate the DHCP IP address, that is,
terminate the Internet connection.
•
Renew. Click the Renew button to renew the DHCP IP address, that is, renew
the Internet connection.
Display the Internet port statistics
To display the Internet port statistics:
1.
Connect your computer or mobile device to the AP in one of the following ways
•
Connect directly to the AP’s WiFi network or LAN. (Applies to the AP in either
operation mode.)
•
Connect to the same network that the AP is connected to. (Applies only if the AP
is operating in AP mode.)
2.
Launch a web browser and enter http://www.routerlogin.net in the address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use routerlogin.net on page 32.
A login window displays.
If your browser displays a security warning, dismiss the warning. For more information,
see Dismiss a browser security warning on page 38.
User Manual156Maintain and Monitor
WiFi 6 AX1800 Dual Band Wireless Access Point WAX204
