4.3 Sorting the Part (Comparator)
4-14 ZM2371/ZM2372
Sounding the beep sound depending on the comparator result
It is able to sound the beep sound according to the comparator result.
The beep sound can be set in the system setting menu.
_
SHIFT
_
+ [ SYSTEM ]
Press the
_
SHIFT
_
+ [SYSTEM] keys to display the system setting menu.
SYSTEM setting
0)INTERFACE 1)BEEPER >NEXT Options (first page)
2)INITIALIZE ALL 3)SELF TEST < > Options (second page)
4)VERSION <PREV Options (third page)
Press the
_
1
_
key to select the BEEPER, and the beeper setting menu is displayed.
BEEPER:OFF Current setting
0)OFF 1)FAIL 2)PASS Options
OFF Disables the beeper (Beep sound stops).
FAIL Allows the beep to sound when the comparator result is failed (other than
BIN1 to BIN14)
PASS Allows the beep to sound when the comparator result is passed (BIN1 to
BIN14)
In case that the limit comparison is enabled: it should be regarded as “PASS” when
comparison result is IN or be regarded as “FAIL” in other cases.
After setting, the results are displayed for a short time and return to one-previous menu.
Perform the EXIT
operation to return to one-previous menu.
_
SHIFT
_
_
EXP
_
| [SYSTEM]
