3.5 Basic Operations
3-21 ZM2371/ZM2372
3.5.3 Simplified Operating Method When You Use Instrument for the First
Time
This section describes the simplified operating method when you use the ZM2371 / ZM2372
for the first time.
Do not connect the handler interface and remote control interface.
Perform operation through the procedure mentioned below:
1) Unlock the key lock
2) Initialize
3) Set measurement conditions
4) Connect and measure the DUT
With the factory default settings, unlocking of key lock and initialization can be omitted.
 Unlock the key lock
When the KEY LOCK lamp lights up, first press the _ SHIFT _ + [KEY LOCK] keys to unlock
the key lock. In concrete terms, after pressing the _ SHIFT _ key, press the _ LOCAL _ | [KEY
LOCK] key with KEY LOCK written above the key.
 Initialize
Press the _ SHIFT _ + [INIT] keys to display the initialize menu, and press the _ 1 _ key to
return to the initial setting state.
When you use the ZM2371 / ZM2372 that has already been set variously, performing the
initialization makes later operations easy. The contents saved in the settings and correction
value memories are not initialized by this operation.
KEY LOCK lamp _ SHIFT _ [KEY LOCK]
[INIT]
