3.5 Basic Operations
3-17 ZM2371/ZM2372
3.5 Basic Operations
3.5.1 Outline of Measurement Screen
During the measurement, the measured value and main settings are displayed on the LCD
display (40 characters  2 lines) of the front panel. Basic contents of display are as shown
below.
Measured value
Lp Ls Cp Cs Rp Rs Z Y G Q D  X B Rs Rp G Lp Rdc
Primary parameter Secondary parameter Measurement frequency
Ls:+1.23456µH Q :+12.3456 1.0000k Hz
A100m FAST256 Int OpShLd2m 0.00 1.00 Vc
1) 2) 3) 4) Vdc Vrms or Arms
Status (main settings: See below) DC Bias Measurement signal level
c: Indicates ALC (constant voltage or
constant current) is enabled
1) RANGE：Measurement range
{Auto | Hold} and impedance measurement range
2) SPEED/AVERAGE：Measurement speed and averaging
{RAP | FAST | MED | SLOW | VSLO} and averaging count
3) TRIG SOURCE
{Int | Man | Ext | Bus}
4) CORRECTION
Op OPEN (Op, Sh, Ld are displayed when enabled)
Sh SHORT
Ld LOAD
Xm Cable lengh {0m | 1m | 2m | 4m}
{ } indicates that either one of options delimited with | is displayed.
