2.2 Installation
2-5 ZM2371/ZM2372
2.2.3 Rack Mounting
ZM2371 / ZM2372 can be mounted on a 19-inch IEC rack, an EIA specification rack or a JIS
standard rack by the use of a rack-mount adapter (optional). The rack-mount adapter is
available with metric type and inch type.
First, mount the rack-mount adapter on the device as shown in “Fig. 2-1 Rack-mount
assembly (mm-rack)” or “Fig. 2-2 Rack-mount assembly (inch-rack)”, and then, mount the
device on the rack.
！
WARNING
When mounting the device on the rack, be sure to install rack rails to support
the ZM2371 / ZM2372. Otherwise, ZM2371 / ZM2372 may fall, causing a human
injury.
！
CAUTION
• When mounting the device on the rack, be sure to install rack rails to support
the ZM2371 / ZM2372. Otherwise, ZM2371 / ZM2372 may fall, causing a product
damage.
• Make sure that the rack is sufficiently air-cooled by providing appropriate
ventilation ports or cooling fans.
• The air inlet of ZM2371 / ZM2372 is provided on both side panels.
Ensure 20mm or more clearance between side panel and wall.
• The air outlet is provided on the rear panel.
Ensure 50mm or more clearance between rear panel and wall.
Higher ambient temperature than the specification or blocking the air inlet or
outlet may reduce the performance or damage the ZM2371 / ZM2372.
