3.3 Operation Tree
3-10 ZM2371/ZM2372
3.3 Operation Tree
An operation tree when ZM2371 / ZM2372 is operated from the panel is shown below.
For the expression of operations, see “3.5.2 Basic Key Operations”.
Operation Tree (1/3)
_ FREQ _ : { Measurement frequency setting menu }
{ Measurement frequency input menu }
_ LEVEL _ : { Measurement signal level setting menu }
_ SHIFT _ + [ALC] : { ALC setting menu }
{ Current setting menu }
_ BIAS _ : { DC bias setting menu }
{ DC bias voltage input menu }
_ SPEED _ : { Measurement speed setting menu }
_ SHIFT _ + [AVERAGE] : { Averaging count setting menu }
_ Pri _ : { Primary parameter selection menu }
Direct selection L / C / R /· · ·
Auto selection Disabled / enabled
_ CKT _ : { Equivalent circuit selection menu }
Series / Parallel
Auto selection Disabled / enabled
_ SHIFT _ + [Pri] : { Primary parameter deviation display menu }
Display format selection
{ Reference value setting menu }
_ Sec _ : { Secondary parameter selection menu }
_ SHIFT _ + [Sec] : { Secondary parameter deviation display menu }
Display format selection
{ Reference value setting menu }
_ AUX DISP _ : { Auxiliary display setting menu } { Bin number input menu }
_ TRIG _ : Manual trigger
_ SHIFT _ + [TRIG MODE] : { Trigger setting menu }
Trigger source selection
{ Trigger delay setting menu }
{ Triggered drive setting menu }
Continued
