3.3 Operation Tree
3-11 ZM2371/ZM2372
Operation Tree (2/3)
_ AUTO/HOLD _ : Measurement range Auto/Manual selection
_ SHIFT _ + [RANGE] : { Measurement range setting menu }
Range switching
{ Minimum output impedance setting menu }
_ SHIFT _ + [OPEN] : { Open correction menu }
Disabled / enabled / measurement { Correction value measurement stop menu }
{ Spot correction menu }
{ Lower limit frequency setting menu }
{ Format setting menu }
{ Correction value input menu }
_ SHIFT _ + [SHORT] : { Short correction menu }
Disabled / enabled / measurement { Correction value measurement stop menu }
{ Spot correction menu } (Open correction & common)
{ Lower limit frequency setting menu } (Open correction & common)
{ Format setting menu }
{ Correction value input menu }
_ SHIFT _ + [LOAD] : { Load correction menu }
Disabled / enabled / measurement { Correction value measurement stop menu }
{ Format setting menu }
{ Standard value input menu }
{ Correction value input menu }
_ SHIFT _ + [CABLE] : { Cable length correction menu }
_ SHIFT _ + [COMPRTR] : { Comparator setting menu }
Disabled / enabled
{ Deviation comparison menu }
Format selection
{ Reference value setting menu }
Initialize
{ Upper / lower limit value setting menu }
Comparison enabled, upper limit value, lower limit value
_ SHIFT _ + [NO LIMIT] : Disabled setting (Don't care)
_ SHIFT _ + [Pri/Sec] : Movement between Primary and Secondary
[PREV] : Movement between all upper and lower limit value (forward
direction)
[NEXT] : Movement between all upper and lower limit value (reverse
direction)
