3.1 Panel Component Names and Functions
3-3 ZM2371/ZM2372
Figure 3–2 Rear panel
Note: This chapter shows the front panel and rear panel of the ZM2372.
The ZM2371 does not have the handler interface, GPIB, and contact check function.
Accordingly, the connectors, labels on the panel, and indication lamps related to these
features are not provided. In the figures, the description about these features is
expressed with a dashed line ------ or outline characters .
When a schematic view of front panel or rear panel is shown in the following
descriptions, the ZM2372 panel is used as a representative.
Power supply
switch
Pushing up turns
the power on,
pushing down
turns it off.
Handler interface connector
