3.5 Basic Operations
3-19 ZM2371/ZM2372
Operation of setting menu
Depending on the key operations, the setting menu will be displayed to select a function or
set a numeric value.
Function selection: When options are displayed on the lower line of the setting menu, an
option can be selected by pressing a numeric key associated with each
option.
Options that cannot be accommodated in one line are displayed over
multiple pages. The pages can be switched with
_
BS
_
| [PREV] key and
_
EXP
_
| [NEXT] key.
Even an option that exists on the page not displayed, it can be selected
with the associated numeric key.
Parameter name and current settings
Parameter_name: Value1 (Value2)
0)alt1 1)alt2 2)alt3 Comments >NEXT
Options
Numeric value input: When the cursor is located at the parameter to which a numeric value
can be entered, the comments such as a range of settable values are
displayed on the lower line of the setting menu. The cursor is displayed
by blinking the digit
The following key operations are possible.
• Numeric keys, decimal point key, sign key : Input a numeric value.
•
_
EXP
_
+ [
_
x
_
] : Input exponential part (x = p, n, , m, k, M) of a
numeric value to enter the value (
_
ENTR
_
need not be
pressed).
For details Input of exponential part.
(Mentioned later)
•
_
ENTR
_
key : Enters the input value.
•
_
BS
_
key : Clears a value being input, one character at a time
from the last.
•
_
SHIFT
_
+ [CE] : Clear a value being input, all at once.
Upon clear of a value being input, the currently set value is displayed.
For the menu that sets multiple parameters, the parameters to be set can
be switched with
_
BS
_
| [PREV] key and
_
EXP
_
| [NEXT] key.
Parameter name and current setting
Parameter_name: Value1 (Value2)
Range of value Comments
Settable range
Indicates that options
exist on another page
To Next Page
