Nikon ECLIPSE Ti2-U User Manual

Chapter 7 Assembly of the Devices
124
Device Description Model Remarks
Diascopic
illumination
filter
Filter slider for dia illumination TI2-D-SF
Recommended when a D-LH/LC
precentered lamphouse is used for
dia-illumination.
Usable filters:
• TI2-D-D 45 Diffuser
• MF45 GIF • MF45 NCB11
• MF45 ND2A • MF45 ND8A
• MF45 ND16A
Diascopic filter (for fixed filter) Assorted models Usable filters:
• ND2 • ND4 • ND8
• ND16 • NCB11 • GIF
• D
Contrast
shield
Contrast shield ELWD TS2-LS For ELWD condenser lens
Contrast shield TS2R-LS
Analyzer Analyzer TI2-C-DICA Mounted in analyzer slider slot
Analyzer block TI-A Mounted on the FL turret
Analyzer cube for large FOV TI2-C-DICACL Mounted on the FL turret
Polarizer DIC polarizer TC-C-DICP
NAMC/IMSI polarizer TC-C-DICPNI
Condenser Condenser turret TC-C-TC System condenser
ELWD-S condenser TE-C Condenser for ELWD
HNA condenser slider TI2-C-SCH Condenser for HNA lens
T-CHNA High N.A. common
condenser lens unit is required.
High N.A. common condenser lens
unit
T-CHNA For HNA lens
DF condenser (oil)
The TI-DF dark-field condenser
adapter is required.
DF condenser (dry)
The TI-DF dark-field condenser
adapter is required.
HNA dry lens TI2-C-LHD
Condenser lens for high NA
objectives
HNA oil lens TI2-C-LHO
Condenser lens for high NA
objectives
LWD condenser lens TI-C-LWD
Condenser lens for
long-working-distance objectives
ELWD condenser lens MC TMD2 ELWD
Condenser lens for
long-working-distance objectives
NAMC condenser lens TI-C NAMC NAMC condenser lens
CLWD condenser lens TI-C-CLWD
Condenser lens for high NA
long-working-distance objectives
The TI2-C-CLWDA CLWD condenser
adapter is required.
CLWD condenser adapter TI2-C-CLWDA For CLWD condenser lens
Condenser adapter TI-DF For dark-filed condenser
Condenser
module
for Ph
microscopy
CLWD PH module TI2-C-MC series For CLWD condensers
LWD PH module TC-C-ML series For LWD condensers
ELWD PH module TC-C-ME series For ELWD condensers
Condenser
module
for DIC
microscopy
LWD dry DIC module TC-C-ML series For LWD condensers
IMSI dry DIC module TC-C-MI series IMSI for LWD condenser
HNA dry DIC module TI2-C-MH series For HNA dry lens
HNA oil DIC module TI2-C-MH series For HNA oil lens
