NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 8
CHAPTER 2 MAINTENANCE
5. Install brake lines. Bleed brakes as described in 2-1 - 1.12.
ft-lbs or strap design bolts to 30-35 ft-lbs.
7. Install exhaust system.
or 85W-140) to level of plug hole
9. Apply a non-hardening sealing compound (like #51 or equivalent) to plug
threads and install and tighten plug.
10 . Turn each wheel so wheel end plug is horizontal to axle shaft. Fill wheel
ends with API GL-5 oil (SAE 80W-90 or 85W-140) to level of plug hole.
Apply a non-hardening sealing compound (like Permatex #51 or
equivalent) to plug threads and install and tighten plugs.
11 . Install wheels. Wheel stud torque is per 2-4 - 4.2.6. NOTE: Axles from the
factory have painted over grease on the wheel hubs. This grease must be
metal.
AUGUST 31, 2008
3 REMOVAL AND INSTALLATION
FIGURE 1. REAR AXLE AND SPRING SUSPENSION
