• Popups Notification Screens
Turning on popups provide a highly visible alert screen when a system Fault, Warning or Alarm occurs�
Figure 1-23: Popup Fault, Warning & Alarm Screens
ALARM
WARNING
FAULT
Alarm Notication Screen
Warning Notication Screen
Fault Notication Screen
Pressing the Enter switch clears the
notication screens�
Pressing the Up or Down switch
displays the Fault, Warning or Alarm
condition detail information screen�
Fault, Warning and Alarm popup screens remain displayed until acknowledged by pressing the Enter
switch� Pressing the Enter switch returns the last displayed CAN parameter prior to the occurrence of
the Fault, Warning or Alarm condition�
For Faults and Warnings, the Fault LED and Warning LED remain illuminated after pressing the Enter
switch to acknowledge and clear the notication screen�
After pressing the Enter switch for Alarms, a blinking "bell" icon appears in the upper left corner of the
CAN parameter display screen to indicate an alarm condition exists�
Pressing the Up or Down switch when a notication screen appears brings up the Fault, Warning or
Alarm detail information display�
Note: If the condition that caused the Fault, Warning or Alarm clears, the notication screens and bell
icon disappears and the alert LEDs turn o�
