2" Stand-Alone CAN Display Operation Manual  SAE J1939
© 2011 Beede Electrical Instrument Co., Inc.
• Set Video
The menu sequence below shows how to set the video mode to either normal or reverse�
Figure 1-30: Setting LCD Background Color Scheme (Video Mode)
Exit
Return
Video-Reverse
Return
Video-Normal
Video Mode
Contrast
Contrast
1-Parameter
Trip Mode
Display
Scroll down to the Exit option and press the Enter switch or
wait 30 seconds for the last displayed CAN parameter to appear�
Pressing the Enter switch toggled the video mode to the
reverse setting�
The setting is automatically saved once changed�
When the selection arrow cursor is placed next to the
Video-Mode option, the name changes to the current video
display mode, i�e�, Video-Normal or Video-Reverse�
Pressing the Enter switch toggles between the two settings�
The setting is automatically saved once changed�
Screen shows Video Mode function prior to placing the
selection arrow cursor next to the function�
Continue to press the Down switch to place the selection
arrow cursor next to the Video Mode function�
The rst two Display Menu functions appear� Scroll to place
the selection arrow cursor next to the Video Mode option�
From the Setup Menu place the selection arrow cursor next to
the Display option, Main Menu-Setup-Display, then press
the Enter switch to view the Display Menu functions�
