1.2.2 Wiring
Wiring should be repaired in accordance with standard automotive practices.
1.2.3 Gaskets and Seals
Gaskets, oil seals, preformed packing, and seals should be replaced instead of
being cleaned and reused, unless otherwise specified by local directives. Replace
any seals and packings that show any deterioration or damage.
Use repair kits when available.
1.2.4 Reassembly and Installation
Unless otherwise specified, reassembly and installation are the reverse of removal
and disassembly. Use the illustrations in parts manual chapter for reference.
1.3 ENGINE REPAIR AND MAINTENANCE
Refer to the operator’s manual supplied by the engine manufacturer (supplied with
this manual) for instructions. More detailed “shop” manuals may be special-ordered
from NMC or can be obtained from a local distributor.
1.3.1 Ordering Parts
If you need parts for your engine, you must provide the complete engine number,
and tractor description, name, and serial number.
The engine number is stamped on a label fastened to the cylinder block.
1.4 FRONT BRAKES
The brake assemblies must be removed as complete assemblies. They cannot be
disassembled while mounted on the front axle.
NOTE: There is no adjustment for caliper-type brakes.
1.4.1 Friction Pad Removal and Installation (Front)
Figure 1
1. Set parking brake. Using a jack, raise tractor high enough off floor to provide
adequate working space underneath the frame. Support tractor with jack stands.
Be sure that positioning of jack stands does not interfere with work task.
2. Remove wheel.
CHAPTER 3 OVERHAUL AUGUST 31, 2008
1 GENERAL REPAIR PAGE 3
M100 Tow Tractor Manual No. 46052
