NMC-WOLLARD 100 - Brake C6 - Parking

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 33
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
12-
NW034879 2598 Brake C6 - Parking, 9x3 (39569)
1
NW034880 2648 Shoe and Lining Kit 9” x 3” 1
2
NW034881 2634 Spring Set - Parking Brake Release 1
3
NW034882 2614 Drum - Parking Brake 1
4
NW034883 22818 Plate - Mounting 1
5
NW034884 2749 Spring - Parking Brake 1
6
NW034885 4446553 Cam & Lever Assy. 1
7
NW034886 2649 Bracket - Cable Support 1
8
NW034887 2A663 Bellcrank 1
9
NW034888 2857 Clevis - Parking Brake Lever 1
10
NW034889 2857 Clevis 1
11
NW034890 2A703 Shield 1
12
F100403 58675 Bolt - 1/2 -13x1.5 Torque 73-107 Nm 4
13
F015973 34794 Lockwasher - 1/2 4
14
F016818 385732 Nut - 1/2 x 13) 4
15
F100403 385524 Bolt - 1/2x13 - 1.5 Torque 73-107 Nm 4
16
F016824 44879 Washer - 1/2 Flat 4
17
F016825 34989 Nut - 1/2x13 Hex 4
18
385554 Stud - 9/16 - 12 - 18x2.28 1
19
385555 Spacer 1
20
41060 44880 Washer - 9/16 Flat 1
21
386034 Nut - 9/16 - 18 Slotted 1
22
72035 Pin - Cotter 1/8x1.0 1
23
76009 Pin - 5/16x1.0 2
24
72009 Pin - Cotter 2
25
N803496 Clip - Vacuum Tube Front 1
26
F101448 58636 Bolt - 3/8 - 16x1.5 Torque 30-43 Nm 1
27
F101331 58638 Bolt - 3/8 - 16x2.0 Torque 30-43 Nm 2
28
F009669 44877 Washer - 3/8 Flat 6
29
2A865 Bracket - Strap 1
30
2A866 Strap 1
31
F101377 58633 Bolt - 3/8-16x.75 Torque 30-43 Nm 2
32
Comm 373603 Washer - 3/8 Flat 2
33
Comm 34987 Nut - 3/8-16 Hex Lock 3
34
F018708 Nut, Hex 3/8-24 1
35
NW036501 D3TZ-7089-B Yoke, Output (26377) 1
36
90652 Clevis, 3/8-24x3/8 1
4 ILLUSTRATED PARTS LIST
AUGUST 15, 2011
