NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 11
CHAPTER 2 MAINTENANCE
3 REMOVAL AND INSTALLATION
AUGUST 31, 2008
9. Tag and disconnect all wire harnesses to engine and transmission components.
10. Disconnect and cap fuel lines at required engine locations.
11. Disconnect accelerator linkage.
12. Disconnect exhaust pipe at the exhaust manifold. Tape over opening to prevent
debris from entering engine.
13. Disconnect drive shaft from parking brake disc and tie out of the way.
14. Disconnect shift cable from transmission.
15.
16. Remove master cylinder/power booster.
17. Remove screws from hood support and slide back to allow clearance for
removing engine/transmission assembly.
18. Loosen cable tension and disconnect parking brake cable from caliper and
bracket.
The engine and transmission assembly is large and heavy. To
prevent it from falling on you, use proper slings and hoists for removal and
installation
19. Attach a suitable hoisting bracket to transmission and/or engine assembly for
support and lifting.
20. Steps 20-25 apply if it is possible to remove the engine without the
transmission.
21. Remove converter drain plug access cover from lower end of converter
housing. Matchmark torque converter with drive plate (for easier installation).
22.
23. Remove converter housing-to-engine attaching bolts.
24. Lower tractor for easier engine removal, if necessary.
25. Remove engine mount capscrews.
NOTICE! The transmission and torque converter must be removed and installed as
an assembly to prevent damage to the front bushing or front oil seal.
26. Move engine away from transmission.
27. Steps 28-33 apply if removing the transmission with the engine.
