NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 24
CHAPTER 2 MAINTENANCE
3. Position drag link so opening in end engages ball on steering arm.
4.
5. Align holes in ends of drag link tube with holes in plugs and install cotter
pins to secure.
6. Cut the 30” plastic sleeve in half and slide onto each front brake hose
7. Connect the new front brake hoses to the front calipers with banjo bolt and
copper washers. Connect the other ends of the hoses to the front cross
over line.
IMPORTANT: There is a RH and LH brake hose. Place a hose block over
the port in the brake caliper. If the steel hose ell from the hose block angle
upward and back it is for this side. If it does not, this hose is for the opposite
side.
8. Bleed the front brakes as instructed in the tow tractor maintenance
manual.
9. Install front wheels and tighten mounting nuts per 2-4 - 4.2.6.
After initially mounting wheel and tire assembly, recheck lug
operation. After this, check monthly or every 250 hours, whichever comes
Failure to follow these procedures could result in wheel mounting failure and
loss of vehicle control.
AUGUST 31, 2008
3 REMOVAL AND INSTALLATION
