NMC-WOLLARD 100 - Page 241

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 3
CHAPTER 4 REPAIR PARTS
JANUARY 31, 2009
4 ILLUSTRATED PARTS LIST
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
1-
41640 Axle - Front, C6 (Brierton), 04-40328C Not Hyd
Cylinder Steering
1
1
41821 Front Axle Weldment,03-30468 1
2
41820 Knuckle, LH, 03-30469 1
3
41819 Knuckle, RH, 03-30470 1
4
41520 Tie Rod Tube Assembly (incl. 4A and 4B), 03-30265 1
4a
NW034967 Tie Rod End Assembly, LH (incl. end, boot, nut, and
cotter pin), 06-60358
Ref
4b
NW034968 Tie Rod End Assembly, RH (incl. end, boot, nut, and
cotter pin), 06-60360
Ref
5
41823 Caliper, Disc Brake, R.H. (NOTE: Casting is stamped L)
See Figure 9, 06-61460L
1
6
41822 Caliper, Disc Brake, L.H. (NOTE: Casting is stamped R)
See Figure 9, 06-61460R
1
7
41521 Hub Assembly (incl. 7A-7E), 02-20608 2
NW036157 Inner Cup 1
NW036159 Outer Cup 1
7a
41522 Hub, Cupped and Studded, 06-61425 2
7b
NW036156 Inner Cone, #25580, 130580500 2
7c
NW036160 Outer Cone, #14125A, 130581300 2
7d
NW036155 Grease Seal,06-60403 2
7e
NW036164 Grease Cup, 06-60402 2
8
NW036842 Nut, 9/16-18 Tapered Wheel, 06-61516 Ref
9
41828 Rotor, 13" Dia.,06-61515 2
10
NW036162 Nut, 1-14 Slotted Hex Jam, 06-62085 2
11
NW036161 Washer, Spindle, 06-60295 2
12
41523 King Pin, 06-60779 2
43586 King Pin Repair Kit for Axle 41640 L 1
NW034782 King Pin Repair Kit early Axle NW36827 K 1
13
41524 Screw, #10 BHC x .63 lg., 06-61080 8
14
F9541 Washer, #10 Lock, 06-61081 8
15
Comm Grease Zerk, 390406410 4
16
41824 King Pin Cap w/ Zerk Hole, 06-60547 4
17
41526 Gasket, King Pin Cap, 06-61376 4
18
3.1666 Nut, Jam, 5/16-18, 321800060 D 2
44153 Nut, Jam, 3/8-24, 06-62089 A 2
19
Comm HHCS, 5/16-18 D 2
44152 Set Screw, Cup Pt, 3/8-24 x .75, 06-62090 A 2
20
43096 Bearing, Thrust T113, 06-61908 2
21
NW034208 Steering Ball, 06-60297 2
22
37813 Nut, 5/8-18 Slotted Hex, 321900110 1
23
Comm Cotter Pin, 3/32 x 3/4 Lg., 324601060 1
24
Comm HHCS 1/2-13x2, 320224100 2
25
Comm Nut 1/2-13 Hex, 321800090 2
26
42097 Stud, Wheel, 9/16-18, Drive In, 06-6142 16
27
42082 Bushing, King Pin, 06-60554 4
28
43583 Caliper Bolt Dust Boot, 06-62065 A 4
