NMC-WOLLARD 100 - Page 243

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 5
CHAPTER 4 REPAIR PARTS
JANUARY 31, 2009
4 ILLUSTRATED PARTS LIST
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
2- 42951 Axle -Front, Deutz 6 H 1
41640-1 Axle -Front, Front Cyl, Rear Tie Rod (OAT39),
04-40355b
H 1
41640-4 Axle - Front, Rear Cyl, Rear Tie Rod, 04-40509 H 1
41640-6 Axle - Front, Rear Cyl, Rear Tie Rod G 1
1 42290 Front Axle Weldment (OAT39), 03-30506b (not for
41640-6)
H 1
2 42291 Knuckle, LH (OAT39), 03-30507 1
3 41819 Knuckle, RH (OAT39), 03-30470 1
4 41520 Tie Rod Tube Assembly (OAT39) (incl. items 4A and
4B), 03-30265 (not for 41640-6)
H 1
4a NW034967 Tie Rod End, LH (incl. end, boot, nut & cotter pin),
06-06358
1
4b NW034968 Tie Rod End, RH (incl. end, boot, nut & cotter pin),
06-60360
1
5 41823 Caliper, Disc Brake, RH (OAT39) (Casting is
stamped L) See Figure 9, 06-61460L
1
6 41822 Caliper, Disc Brake, LH (OAT39) (Casting is
stamped R) See Figure 9, 06-61460R
1
7 41521 Hub Assembly (incl. 7A-7E) (OAT39), 02-20608 2
a 41522 Hub, Cupped and Studded (OAT39), 06-61425 2
b NW036156 Inner Cone, #25580 (OAT39), 130580500 2
c NW036160 Outer Cone, #14125A (OAT39), 130581300 2
d NW036155 Grease Seal (OAT39), 06-60403 2
e NW036164 Grease Cup (OAT39), 06-60402 2
8 NW036842 Nut, 9/16-18 Tapered Wheel (OAT39), 06-61516 16
9 41828 Rotor, 13" Dia. (OAT39), 06-61515 2
10 NW036162 Nut, 1-14 Slotted Hex Jam (OAT39), 06-62085 2
11 NW036161 Washer, Spindle (OAT39),06-60295 2
12 41523 King Pin (OAT39),06-60779 2
43586 King Pin Repair Kit for Axle 41640-1 P 1
NW034782 King Pin Repair Kit early Axle NW36827 O 1
13 41524 Screw, #10 BHC x .63 Lg. (OAT39), 06-61080 8
14 F009541 Washer, #10 Lock, 06-61081 8
15 Comm Grease Zerk, 390406410 4
16 41824 King Pin Cap, Std (OAT39), 06-60547 4
17 41526 Gasket, King Pin Cap (OAT39), 06-61376 4
18 F100568 Nut, Jam, 5/16-18 C 2
44153 Nut, 3/8-24 Jam, 06-62089 B 2
19 Comm HHCS, 5/16-18 C 2
44152 Set Screw, 3/8-24 x .75 Cup Pt., 06-62090 B 2
20 43096 Bearing, Thrust (OAT39), 06-61908 2
21 Comm HHCS, 1/2-13 UNC x 2.00 Lg., 320224100 2
22 F016825 Nut, 1/2-13 UNC Hex, 321800090 2
23 42097 9/16-18 Drive In Wheel Stud,06-61426 16
24 42082 King Pin Bushing, 06-60554 4
25 43583 Caliper Bolt Dust Boot, 06-62065 B 4
