NMC-WOLLARD 100 - Page 245

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 7
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
3-
44245 Axle - Front Spring Ref
1
46478 Hanger Wldmnt, Spring E 2
41236 Spring Hanger F 2
46809 Spring Hanger 24.5” Spring CTRS G 2
2
F015973 Lock Washer, 1/2 4
3
NW036316 HHCS, 1/2-13 x 1.75, GR 8 4
4
41246 FHSHCS, 1/2-13 x 1.75 4
5
41847 U-Bolt, 9/16-18 x 7.75 (6H839) 4
6
39076 HHCS, 5/8-11 x 4.50 2
7
Comm Lock Washer, 5/8 2
8
39077 HHCS, 5/8 -11, 5.00, GR 8 2
9
F016453 Hex Nut, 9/16-18 6
10
F100078 Lock Washer, 9/16 8
11
NW033761 Spring Plate 2
12
40986 Spring, Heavy Duty (6H839) 2
13
41238 Lock Washer, 1/2 Shakeproof, CTSK 4
14
45695 Plate, Top, U-Bolt, 6” S 2
15
12654.36 U-Bolt, Rd, 9/16-18 S 4
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2007
