NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 9
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
4-
44314 Rear Spring Suspension, 8000 DBP, Option Ref
44315 Rear Spring, 10-12,000 DBP, Optional
53388 Grp, M100 Axle, Mnt, Spring, 8K P
53387 Grp, M100 Axle, Mnt, Spring, 10-12K Q
1
40974 Rear Spring, 4,000 lb., 12 Leaf, 3.88" Stack 2
41509 Rear Spring, For 10-12,000 DBP (6H839) 2
2
42055 U-Bolt, 3/4-16 4
3
39077 HHCS, 5/8-11, 5.00, GR 8 4
3A
NW023102 Bushing, Rear Axle 2
4
39058 Torque Rod 2
5
39076 HHCS, 5/8-11, 4.50, GR 8 6
5A
39463 Mount, Torque Rod, LH 1
39082 Mount, Torque Rod, RH 1
53378 Mount, Torque Rod, Newage P 2
6
41047 Shackle Plate (V00507) 4
8
42066 Plate, Torque Rod Mount 2
53592 Plate, Torque Rod Mount Q
9
44313 Axle Mount, Solid (See page 10) Ref
42067 Plate, Torque Rod Mount 2
53593 Plate, Torque Rod Mount
Q
2
10
42040 Snubber Leaf Spring 2
11
42037 Plate, Top, U-Bolt 2
12
42111 Nut, Hex 1/2-13, Lock Flange, GR 8 6
13
3.0391 Nut, Hex 5/8-11, Nylock, GR 8 6
14
42113 HHCS 1/2-13 x 4-1/2, Flange, GR 8 4
15
42114 HHCS 1/2-13 x 5, Flange, GR 8 2
16
F016828 Washer, 5/8 Flat 6
17
42112 Nut, Hex 5/8-11, Flange Lock 4
NS
NW036517 Pad, Reworked, RW Axle, LH (for 40465, 41508) 1
NS
F103924 Plastic Sleeve Coil (for 40465, 41508) 8
NS
39078 F. HHCS, 5/8-11 x 6.5 GR8
P
2
4 ILLUSTRATED PARTS LIST
MAY 15, 2016
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
4-
51375
Shackle Bolts, Greaseable, Option
Ref
3
51376 F,HHCS, 5/8-11 x 5.0, Greaseable
O
4
6
51374
F,HHCS, 5/8-11 x 4.50, Greaseable (See Fig 3)
O
8
