M100 Tow Tractor Manual No. 46052
PAGE 15
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
6-
Axle-Rear, 2 of 2 Ref
18
Case, Di󰀨erential, Flange Half Kit, Di󰀨erential-
Case Assembly (includes items 6-8 and 18),
A2-3235-N-1262
1
Ref
19
39165 Washer, Hardened (69633), 1229-E1513 12
20
39166 Nut (69633), NL-17-1 12
21
39167 Gasket, Carrier Halves (69633), 2208-H-112
22
39168 Carrier and Tube Assy, Plain Half (includes items 4
and 26-28), A43-3200S-487
1
23
39169 Oil Breather (69633), A-1199-C-1043 1
24
39166 Nut (69633),NL-17-1 11
25
39165 Washer, Hardened (69633), 1229-E-1513 11
26
39185 Plug, Fill/Drain, Magnetic (69633), 1850T150 1
27
39170 Thrust Block (69633), 2297-S-175 1
28
39171 Pin, Thrust Block (69633), 1246-D-134 1
30
39172 Lock Ring, Bevel Pinion RR, 1229-Y-1299 1
31
39173 Bearing, Bevel Pinion RR (69633), 1228- 1
32
Pinion, Bevel (See item 17) 1
33
39174 Cone, Pinion Bearing (69633), HM-803149 2
34
39175 Cup, Pinion Bearing (69633), HM-303110 2
35
39176 Dowel, Bearing Cage (69633), 1246-C-211 1
36
39177 Bearing Cage Assembly (69633) (includes items 33
and 34), A1-3226-A-677
1
37
Same as item 49
38
Same as item 48
39
NW036853 Gasket (69633), 2808E863 1
40
39181 Cover Assembly (incl. item 41), A-3266-W-49 1
41
NW036980 Oil Seal, Pinion Cage Cover, A-1205K167 1
42
43062 Nut, Lock, Pinion
43
Comm Key (69633) 1
44
41935 Input Yoke For U-Bolt Connection (69633),
141NYT22-22
1
41496 Input Yoke For Flat Shaft To Shaft Connection
(69633), 3897Q1993
1
45
39183 Capscrew, Long (69633), S-2912-2 5
39184 Capscrew, Short (69633), S-2910-1 1
46
39182 Washer (69633), 1229-X-1558 6
47
39179 Nut (69633), 1227-M-117 2
48
39180 Lock, Bevel Pinion Nut, 1229-H-528 1
49
39178 Thrust Washer (69633),1229-J-530 2
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2007
