NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 17
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2007
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
7-
Axle - Rear, Wheel End (3E157) Ref
1
39183 Capscrew (69633), S-2812-1 32
2
39155 Washer, Hardened (69633), 1229-C-1511 32
3
39185 Plug, Fill/Drain, Magnetic (69633), 2850-T-150 2
4
39186 Spider Assembly (includes item 10) (69633),
A1-3298-B-1094
2
5
39187 Setscrew, Pinion Shaft (69633), 26-X-237 6
6
39188 Shaft, Planetary Pinion (69633), 3198-W-1089 6
7
39189 Pinion, Planetary (69633), 3891-Q-1629 6
8
39190 Thrust Washer (69633), 1229-F-2814 6
9
39191 Snap Ring (69633), 1854-Z-182 6
10
39192 Thrust Button (69633), 2297-T-4570 2
11
Snap Ring (69633), 1854-Z-182 2
12
39194 Gear, Planetary Sun (69633), 3892-Z-3588 2
13
39195 Axle Shaft (69633), 3202-E-9911 2
14
39196 Gear, Planetary Ring (69633), 3892-C-4059 2
15
39197 Dowel (69633), 1246-G-553 2
16
39198 Lock Nut Assy (Includes Item 15), A-1227-J-972 2
17
NW015764 Cone, Outer (69633), 3326B 2
18
NW015766 Cup, Outer (69633), 33462 2
19
41168 Hub Assembly, 9/16” studs (incl. 18, 20, and 21)
(69633),333-S-4283
2
20
41063 Stud, Wheel, 9/16" (Sam's), 675046 16
21
NW015767 Cup, Inner (69633), 394AS 2
22
NW015769 Cone, Inner (69633), 399AS 2
23
NW036855 Oil Seal (69633),A1805E369 2
24
NW036856 Brake Drum (69633), 3219A5097 2
25
39155 Washer, Hardened (69633), 1229-C-1511 24
26
39199 Capscrew (69633), S-2812-A1 24
